PERFORMANCE ADVANTAGES
Finest particle size available in Dicyanex product series for maximum reactivity
• Easily dispersed in liquid resins
• Shelf stability of up to 6 months @ 25°C in properly formulated systems
• Activation temperature can be varied easily from 180°C-95°C with appropriate accelerator selection
APPLICATIONS
• One-component adhesives
• Recreational and industrial pre-preg Composites
• Powder coatings
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for CNX-20545-68 curing agent.
TYPICAL CURE SCHEDULE
1-2 hr @ 180°C
| TYPICAL PROPERTIES | |
| Appearance | White, Crystalline Particles |
| Melting point (°C) | 209-212 |
| Particle Size (Microns) | |
| D90 < 10um | |
| D50 < 5um | |
| DICY purity, % | 99 * |
| Equivalent Wt/{H} | 21 |
| Recommended Use level (phr, EEW=190) | 4-15 |
| TYPICAL HANDLING PROPERTIES * | |
| Gel Time (month) (150g mix @ 25°C) | 12 |
| SUGGESTED ACCELERATORS |
| Amicure UR-D |
| TYPICAL PERFORMANCE | |
| Tg (℃) ** | 120 |
When accelerated with Amicure UR-D | 120-130 *** |
* Purity without flow control additive
** Measured using DSC with 10℃/min ramp
*** The range depend on different usage
