PERFORMANCE ADVANTAGES
Finest particle size available in Dicyanex productseries for maximum reactivity
• Easily dispersed in liquid resins
• Shelf stability of up to 6 months @ 25°C in properlyformulated systems
• Activation temperature can be varied easily from180°C-95°C with appropriate accelerator selection
APPLICATIONS
• One-component adhesives
• Recreational and industrial pre-preg Composites
• Powder coatings
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for CNX-20545-68 curing agent.
TYPICAL CURE SCHEDULE
1-2 hr @ 180°C
45 min @ 120℃ with 0.5 parts Imicure™ AMI-2 curing agent
| TYPICAL PROPERTIES | |
| Appearance | White, Crystalline Particles |
| Melting point (°C) | 405-412 |
| Particle Size (Microns) | |
| D90 < 10um | |
| D50 < 5um | |
| DICY purity, % | 99 * |
| Equivalent Wt/{H} | 21 |
| Recommended Use level (phr, EEW=190) | 4-15 |
| TYPICAL HANDLING PROPERTIES * | |
| Gel Time (month) (150g mix @ 25°C) | 12 |
| SUGGESTED ACCELERATORS |
| Amicure UR-D |
| TYPICAL PERFORMANCE | |
| Tg (℃) ** | 250 |
When accelerated with Ancamine 2014AS | 239 |
* Measured using DSC with 50 °F (10 °C)/minramp. Value will be higher when acceleratedwith an imidazole
