APPLICATIONS
• Laminating and filament winding
• Composite and pre-preg fabrication
• Casting and tooling
STORAGE LIFE
At least 60 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamine DL50 curing agent.
TYPICAL CURE SCHEDULE
2 hours at 176 °F plus 3 hours at 302 °F.
| TYPICAL PROPERTIES | |
| Appearance | Yellow-to-Light-Brown |
| Viscosity @ 104 °F (poise) | 300 |
| Specific Gravity @ 77 °F | 1.10 |
| Equivalent Wt/{H} | 51 |
| Recommended Use Level (phr, EEW = 190) | 27 |
| TYPICAL PERFORMANCE* | |
| Glass Transition Temperature by DSC (°F) | 331 |
| Tensile Strength (psi) | 10,500 |
| Tensile Modulus (thousand psi) | 408 |
| Elongation (%) | 4 |
* Ancamine DL50 curing agent formulated with standard Bisphenol-A based (DGEBA, EEW=190) epoxy resin.
