ADVANTAGES
.Good corrosion resistance
·Rapid touch dry with solid epoxy resins
.Good colour and light stability
.Compatible with wide range of solvents
APPLICATIONS
.Solvent based marine & protective coatings
.Primers, sealers and coatings for concrete
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.Do not freeze.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for
Ancamide 221 curing agent.
|
TYPICAL PROPERTIES |
|
| Appearance | Clear amber liquid |
| Colour1(Gardner) | 9 max |
| Viscosity2@40°℃[mPa.s] | 42300 |
| Amine Value 3[mg KOH/gl] | 205-235 |
| Specific Gravity @21℃ | 0.99 |
| Recommended use Level 4[phrl] | 35-50 |
| TYPICAL HANDLING PROPERTIES * | |
| Pot Life5 [hrs] | >7hrs |
| Thin Film Set Time6 25°C[hrs] | 4.5 |
| Set to touch(finger) [hrs] | 1.5 |
| Hard dry thumb twist [hrs] | 7.5 |
*Ancamide 221 curative cut to 70% solids in xylene and solution used at 50 phr with solid epoxy resin
| TYPICAL CURE SCHEDULE |
| (1)2-7 Days at Room Temperature |
|
FILM PROPERTIES AFTER 10 DAYS CURE @23℃ |
|
| Perzoz Hardness | 315 |
| Direct impact [cm.kg] | 200 |
| Reverse impact [cm.kgl] | 200 |
| Flexibility Cylindrical Mandrel7(mm pass) | 3 |
1 ASTM D 1544-80
2 Brookfield RVTD,Spindle 4
3 Perchloric Acid Titration
4 Theoretical value with Bisphenol A diglycidyl ether(EEW=500). calculated based on resin usage@ 100% solids
5 Clear coat formulation,time to double in viscosity
6 BK Drying Recorder Phase l
7 Erichsen mandrel tester 266
