APPLICATION
Coal tar epoxy coating
Epoxy primer for concrete
CHARACTERISTICS
Fast dry and good adhesion to damp surface.
Good resistance to chemicals and solvents.
PACKING
180kgs nett in Steel Drum
SAFETY AND HANDLING PRECAUTIONS
Always ensure that all health and safety procedures are in accordance with local and national Goverment requirements. Normal handling precautions should be observed, and in the event of contamination the affected parts should be washed with soap and water.
| SPECIFICATION | |
| Amine Value | 150 ± 10 |
| Acid Value | 3> |
| Color No (G/H) | 12> |
| Viscosity (CPS at 25°C) | 2000 ~ 6000 |
| Non Volatile% | 70 ± 2% |
AHEW 190 (solid) ; 271 (solution)
| FORMULATION RATIO (by solid) | |
| EPOXY RESIN | SUNMIDE 390-70 |
| Semi solid type epoxy resin (EEW = 230 ~ 270) 100parts | 76 (70 ~ 80) |
| Solid type epoxy resin (EEW = 450 ~ 500) 100parts | 40 (38 ~ 42) |
POT LIFE : Formulation #1 300g Mass = 3 hours
| CURING PROPERTIES (at 20ºC) | ||
| Formulation | #1 | #2 |
Drying time (wet 200μ) Curing time (wet 200μ) (RCI Drying recorder) | 4.8 hours 24.9 hours | 8.1 hours 27.2 hours |
Pencil hardness 1 day (wet 300µ) 2 days 3 days 7 days 30 days | HB F H H H | HB F F F H |
Formulation #1 DER#661-60% (EEW=791) SUNMIDE 390-70 | 100parts 34parts |
| 134parts | |
Formulation #2 DER 337-70% (EEW=357) SUNMIDE 390-70 | 100parts 76parts |
| 176parts |
# DER 661-60% : Solid type epoxy resin DER-661 60% solution of xylene / iso-butanol
# DER 337-70% : Semi solid type epoxy resin DER 337 70% solution of toluene
