ADVANTAGES
• Ultra-fast curing at room or low temperature
• Low smell
• Rapid mechanical strength built speed
• High adhesion to various substrates
APPLICATION
• 2K adhesives
• Electronic Adhesive & Composites
• Bonding & Repairing
TYPICAL CURE SCHEDULE
• 30mins-7days for fully cure at room temperature
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamine 2914UF.
| TYPICAL PROPERTIES | |
| Appearance | Clear light yellow liquid |
| Colour① (Gardner) | max 4 |
| Viscosity②at 25 °C (mPa·s) | 500~1500 |
| Amine Value③(mg KOH/g) | 450~550 |
| Recommended use level④ (phr) | 50 |
| TYPICAL HANDLING PROPERTIES④ | |
| Gel time at 25 °C, 20 g mixed mass (min) | 6 |
| *50 phr | |
| TYPICAL PERFORMANCE④ | |
| (7 day cure @ 25°C) | |
| Adhesion strength@25°C 1h, steel, lap shear (MPa) | 8 |
| Adhesion strength@25°C 1D, steel, lap shear (MPa) | 16 |
| Tensile elongation (%) | 4 |
Tensile strength (MPa) | 80.5 |
| *50 phr, cure 40 °C/24 hr | |
1. ASTM D 1544-80
2. Brookfield RVTD, spindle 27
3. Perchloric acid titration
4. With a standard bisphenol A-type epoxy resin (EEW=190)
