PERFORMANCE ADVANTAGES
• Outstanding flexibility and peel strength
• Excellent thermal shock resistance
• Good electrical properties
• Lower viscosity than standard polyamides
• Excellent adhesion to a wide variety of substrates
• DOT noncorrosive
APPLICATIONS
• Electronic potting and encapsulation compounds
• General-purpose, two-component adhesives where improved adhesion/peel strength is required
• Coatings, civil engineering and composites applications where improved flexibility/crack resistance/adhesion is required
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamide 910 curing agent.
TYPICAL PROPERTIES | |
| Appearance | Amber liquid |
| Colour(1)(Gardner) | 6 |
| Viscosity(2)@ 25 °C(cP) | 6,000 |
| Amine Value(3), [mg KOH/g] | 118 |
| Specific Gravity(4) @ 25 °C | 0.99 |
| Flash Point(5) (°C) | >93 |
| Equivalent Wt/{H} | 230 |
| Recommended Use Level (phr, EEW=190) | 110-125 |
| TYPICAL HANDLING PROPERTIES* | |
| Mixed Viscosity(6) @ 25 °C (cP) | 6640 |
| Gel Time(7) (150g mix @ 25 °C) (min) | 120 |
| Thin Film Set Time(8) @ 25 °C (hr) | 8 |
| Peak Exotherm(9) (100 g mass) (°C) | 65 |
| TYPICAL PERFORMANCE* | |
| (7 days cure @ 25 °C) | |
| Glass Transition Temperature(10)(°C) | 25 |
| Tensile Strength(11) (psi) | 1000 |
| Tensile Modulus(11) ( thousand psi) | 114 |
| Tensile Elongation at break(11) (%) | 100 |
| Hardness(12) (Shore D) | 57 |
*Ancamide 910 curing agent formulated with standard Bisphenol-A based (DGEBA, EEW=190) epoxy resin.
FOOTNOTES:
1 ASTM D 1544-80
2 ASTM D 455-83, Brookfield RV, Spindle 27
3 Perchloric acid titration
4 ASTM D 147-85
5 Seta flash closed cup
6 ASTM D 455-83, Brookfield RV, Spindle 52
7 Techne GT-4 gelation timer
8 BK drying recorder
9 ASTM D 2471-71
10 ASTM D 3418-82
11 ASTM D 638-86
12 ASTM D 2240-86
