PERFORMANCE ADVANTAGES
• Excellent chemical resistance
• Good low temperature cure
APPLICATIONS
• Non-colour sensitive applications
• Industrial flooring, screeds, primers, grouts
• Cost sensitive applications
• Chemical resistant tank linings
• High solids coatings
• Secondary containment
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers. Do not freeze.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamine 2686 curing agent.
TYPICAL CURE SCHEDULE
Gel at room temperature plus 2 hours at 212 °F.
| TYPICAL PROPERTIES | |
| Appearance | Yellow Liquid |
| Color① (Gardner) | max 12 |
| Viscosity② @ 25 °C [mPa.s] | 100-400 |
| Amine Value③ (mg KOH/g) | 300-350 |
| Specific Gravity @ 21 °C | 1.0 |
| Equivalent Wt/{H} | 95 |
| Recommended use Level④ [PHR] | 50 |
| TYPICAL HANDLING PROPERTIES④ | |
| Gel Time ⑤ (150g mix at 25°C) [mins] | 35 |
| Thin Film Set Time ⑥ 25°C [h] | 4.0 |
| Hardness Shore D ⑦ at 25°C (24h) | 78 |
| Hardness Shore D ⑦ at 10°C (24h) | 70 |
| Typical cure schedule 2- 7 days | |
| TYPICAL HANDLING PROPERTIES ④ | |
| Compressive Strength ⑧, [MPa] | 90 |
| Compressive Modulus ⑧, [GPa] | 2.2 |
| Flexural Strength ⑨, [MPa] | 93 |
| Flexural Modulus ⑨, [GPa] | 3.0 |
| Heat Distortion Temperature ⑩, [°C] | 50 |
| Carbamation Test ⑪ | 4 |
1 ASTM D 1544-80
2 Brookfield RVTD, Spindle 4
3 Perchloric Acid Titration
4 With Bisphenol A diglycidyl ether (EEW=190)
5 Techne GT-3 Gelation Timer
6 BK Drying Recorder Phase III
7 DIN 53505
8 ISO 604
9 ISO 178
10 ASTM D648
11 ISO 2812 (Wet Patch Method), scale 1-5 (5 is best)
