ADVANTAGES
• Broad Application and Service Temperature Range
• High Corrosion and Chemical Resistance
• Very Cost Effective
• High Blush Resistance
• Good Cathodic Disbondment Resistance
• Good Flexibility and Adhesion
• 100% Active
APPLICATIONS
• Pipeline Coatings
• Metal Primers
• Corrosion Resistant Primers & Build Coats
• Chemical Resistant Tank Linings
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamide 2634SF curing agent.
TYPICAL CURE SCHEDULE
Ambient: 2−7 days
Heat Cure: 2-4 hrs at 120°C
|
TYPICAL PROPERTIES |
|
| Appearance | Amber Color Resinous Liquid |
| Colour1(Gardner) | 8 |
| Viscosity2@ 25 °F (cPs) | 113,000 |
| Viscosity @ 40 °F (cPs) | 15,000 |
| Viscosity @ 50 °F (cPs) | 5,000 |
| Amine Value3 (mg KOH/g) | 410 |
| Specific Gravity4 @ 77 °F | 1.05 |
| Equivalent Wt/{H} | 73 |
| TYPICAL HANDLING PROPERTIES * | |
| Use Level (phr) | 38-42 |
| Glass Transition Temperature 5 (C°) | 115 |
*Cured with liquid Bisphenol-A based epoxy resin (EEW=190)
Footnotes:
1 ASTM D 1544-80
2 ASTM D 445-83, Brookfield, RVTD, Spindle 4
3 Perchloric Acid Titration
4 ASTM D 1475-85
5 ASTM D 3418-82 7 Maximum Tg = 240 °F when sample is fully heat cured
