PACKING
180kgs net in Steel Drum
| SPECIFICATION | |
| Amine Value | 455 ± 30 |
| Colour (Gardner) | 12 max. |
| Viscosity (mPa.s / 25ºC) | 5000 ~ 8000 |
AHEW 90
BLENDING RATIO “A” Epikote 828 : Sunmide 336 = 70 : 30
| CURING CHARACTERISTICS | |
| Gel time (100g mass at 20℃) | 86 mins |
| Pot Life (100g mass, at 20ºC) | 60 mins |
| Initial drying time (100μ at 20℃) *1 | 4.0 hrs |
| Initial curing time (100μ at 20℃) *1 | 13.0 hrs |
| PHYSICAL PROPERTIES | |
Shear strength (Hard PVC – Hard PVC)*2 | 19.7 Kg/cm² |
Shear strength (Al – Al) /cm²)*3 | 40.0 Kg/cm² |
Adhesion (Slate plate – Soft PVC)*4 | Material destruction |
BLENDING RATIO “B” Epikote 828 / Sunmide 336 / Union Carbide A-1120 = (70 / 29.4 / 0.6)
| PHYSICAL PROPERTIES | |
| Shear strength (Al – Al)*3 | 80.0 Kg/cm² |
| Shear strength (Al – Soft PVC)*5 | 8.3 Kg/cm²(Material destruction) |
| Peel strength (T-shape, Al – Al)*6 | 1.6 Kg/cm² |
*1. RCI drying recorder
*2. JIS K 6850 Hard PVC – Hard PVC, curing at 80ºC for 2 hrs.)
*3. JIS K 6850 Al – Al, curing at 20ºC for 7 days.
*4. Slate plate – Soft PVC, curing at 20ºC for 7days and another 7days immerse in water.
*5. JIS K 6850 Al – Soft PVC, curing at 20ºC for 7 days.
*6. JIS K 6854 Al – Al, curing at 20ºC for 7 days.
