PERFORMANCE ADVANTAGES
• Rapid property development
• Fast cure at low temperature
• Low Viscosity
• Good mechanical properties
• Easy to formulate 1:1 ratio system
APPLICATIONS
• Concrete structural reinforcement
• Epoxy overlay
• Dry-fixing adhesive
• General purpose adhesive
STORAGE LIFE
At least 12 months from the date of manufacture in the original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers. Do not freeze.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamine 2777 curing agent.
TYPICAL CURE SCHEDULE
1-7 Days at Room Temperature
| TYPICAL PROPERTIES | |
| Appearance | Amber Color Liquid |
| Colour① (Gardner) | 18 max |
| Viscosity② @ 25°C [mPa.s] | 60~300 |
| Amine Value③ [mg KOH/g] | 320~390 |
| Specific Gravity @ 25°C [g/ml] | 0.99 |
| Equivalent Wt/{H} | 165 |
| Recommended Use Level④ [PHR] | 60~90 |
| TYPICAL HANDLING PROPERTIES④,⑦ | |
| Mixed Viscosity② @ 25°C [mPa.s] | ~900 |
| Gel Time⑤ (150g mix at 25°C), [min] | 15 |
| Thin Film Set Time⑥ 25°C, [hrs] | 2.2/3.8 |
| Thin Film Set Time⑥ 5°C, [hrs] | - |
| TYPICAL PERFORMANCE PROPERTIES⑦ | A⑧ | B⑨ |
| Lap Shear Strength (MPa) | 14.1 | - |
| Tensile Strength (MPa) | - | 51 |
| Tensile Mondulus (MPa) | - | 2130 |
| Elongation (%) | - | 4.9 |
| Compressive Strength (MPa) | - | - |
| Compressive Mondulus (MPa) | - | - |
| Epoxy Resin④ | part | 100 | 100 | 100 |
| Ancamine 2777 | phr | 60 | 80 | 90 |
| Tensile⑩ | Strength (MPa) | 49 | 36.7 | 14.5 |
| Elongation (%) | 4.1 | 10.2 | 57.6 | |
| Modulus (MPa) | 2180 | 1670 | 680 |
1 ASTM D 1544-80
2 Brookfield RVTD, Spindle 4
3 Perchloric Acid Titration
4 with Bisphenol A diglycidyl ether (EEW=190)
5 Techne GT-4 Gelation Timer
6 BK Drying Recorder Phase III
7 Loading is 80 phr
8 1 day cure @ 5 °C
9 7 days cure @ 25 °C
10 1 day cure @ 40 °C
