PERFORMANCE ADVANTAGES
•Good flexibility and strength
•Flexible and easy in formulation adjustment
•Excellent weatherability and aging resistance
•Long term retention of mechanical properties
•Excellent chemical resistance
•Excellent impact resistance
•Excellent thermal shock resistance
APPLICATIONS
• Epoxy multi-layer overlay for skid resistance on concrete, asphalt and steel substrate
•Transition layer of bridge deck
•Resilient sealant
•Sandwich panel bonding
•Coating primer
STORAGE LIFE
At least 24 months from date of manufacture in original sealed container at ambient temperature. Store away from excessive heat and humidity in tightly closed containers.Do not freeze.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Ancamide 2766 curing agent.
TYPICAL CURE SCHEDULE
1-7 Days at Room Temperature
TYPICAL PROPERTIES | |
| Appearance | Amber Color liquid |
| Colour1(Gardner) | 10 max |
| Viscosity2@ 25 °C (mPa.s) | 1000~3000 |
| Amine Value3(mg KOH/g) | 255~295 |
| Specific Gravity@ 21° C, [g/ml] | -- |
| Equivalent Wt/{H} | 120 |
| Recommended use Level2 , [PHR] | 80 |
TYPICAL HANDLING PROPERTIES 4,7 | |
| Mix Viscosity 2 @ 25° C, [mPa.s] | 1600 |
| Gel Time 5 (150g mix at 20° C), [min] | 37 |
| Thin Film Set Time 6 20° C, [hrs] | 5 |
| Thin Film Set Time 6 10° C, [hrs] | 14 |
TYPICAL PERFORMANCE PROPERTIES 4,7 | A8 |
| Lap Shear Strength (MPa) | 21 |
| Tensile Strength (MPa) | 14 |
| Tensile Modulus (MPa) | 480 |
| Elongation (%) | 42 |
| Compressive Strength (MPa) | 30 |
| Compressive Modulus (MPa) | 960 |
| Shore D 8hr/1d/7d/510d @ 25C | 25/52/59/60 |
1 ASTM D 1544-80
2 Brookfield RVTD, Spindle 4
3 Perchloric Acid Titration
4 with 90% Bisphenol A diglycidyl ether (EEW=190) and 10% Epodil 748 (C12-C14 alkyl glycidylether) blend
5 Techne GT-4 Gelation Timer
6 BK Drying Recorder Phase III
7 Loading is 80 phr
8 1 days cure @ 40° C
